Experience next-level desktop performance with the Intel Core i7-14700 LGA1700 2.1GHz 20-Core Processor – engineered to accelerate gaming, content creation, and demanding multitasking workloads. Built on Intel’s innovative 14th Gen hybrid architecture, this high-performance CPU features a significant increase in core count, intelligently combining Performance-cores (P-cores) and Efficient-cores (E-cores) to deliver optimal responsiveness across diverse applications.
FEATURES:
- 20 Cores and 28 Threads: Optimised for multitasking and high-performance computing
- Max Turbo Frequency of 5.4 GHz: Delivers swift and responsive processing speeds
- Intel UHD Graphics 770: Supports high-resolution displays up to 7680 x 4320 at 60Hz
- Supports DDR5 and DDR4 Memory: Compatible with up to DDR5 5600 MT/s and DDR4 3200 MT/s memory types
- PCIe 5.0 and 4.0 Support: Offers up to 20 PCI Express lanes for high-speed data transfer
- Intel Turbo Boost Max Technology 3.0: Enhances performance by identifying and boosting the fastest cores
- Efficient Thermal Design: Operates with a Processor Base Power of 65 W and Maximum Turbo Power of 219 W
SPECIFICATIONS:
- Essentials:
- Product Collection: Intel Core i7 Processors (14th gen)
- Code Name: Products formerly Raptor Lake
- Vertical Segment: Desktop
- Processor Number: i7-14700
- Lithography: Intel 7
- CPU Specifications:
- Total Cores: 20
- # of Performance-cores: 8
- # of Efficient-cores: 12
- Total Threads: 28
- Max Turbo Frequency: 5.4GHz
- Intel Turbo Boost Max Technology 3.0 Frequency: 5.4GHz
- Performance-core Max Turbo Frequency: 5.3GHz
- Efficient-core Max Turbo Frequency: 4.2GHz
- Performance-core Base Frequency: 2.1GHz
- Efficient-core Base Frequency: 1.5GHz
- Cache: 33 MB Intel Smart Cache
- Total L2 Cache: 28 MB
- Processor Base Power: 65 W
- Maximum Turbo Power: 219 W
- Memory Specifications:
- Max Memory Size (dependent on memory type): 192 GB
- Memory Types:
- Up to DDR5 5600 MT/s
- Up to DDR4 3200 MT/s
- Max # of Memory Channels: 2
- Max Memory Bandwidth: 89.6 GB/s
- ECC Memory Supported: Yes
- GPU Specifications:
- GPU Name: Intel UHD Graphics 770
- Graphics Base Frequency: 300MHz
- Graphics Max Dynamic Frequency: 1.6 GHz
- Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
- Execution Units: 32
- Max Resolution (HDMI): 4096 x 2160 @ 60Hz
- Max Resolution (DP): 7680 x 4320 @ 60Hz
- Max Resolution (eDP – Integrated Flat Panel): 5120 x 3200 @ 120Hz
- DirectX* Support: 12
- OpenGL* Support: 4.5
- OpenCL* Support: 3.0
- Multi-Format Codec Engines: 2
- Intel Quick Sync Video: Yes
- Intel Clear Video HD Technology: Yes
- # of Displays Supported: 4
- Device ID: 0xA780
- Expansion Options:
- Direct Media Interface (DMI) Revision: 4.0
- Max # of DMI Lanes: 8
- Scalability: 1S Only
- PCI Express Revision: 5.0 and 4.0
- PCI Express Configurations: Up to 1×16+4, 2×8+4
- Max # of PCI Express Lanes: 20
- Package Specifications:
- Sockets Supported: FCLGA1700
- Max CPU Configuration: 1
- Thermal Solution Specification: PCG 2020C
- TJUNCTION: 100°C
- Package Size: 45.0 mm x 37.5 mm
- Max Operating Temperature: 100 °C
- Advanced Features:
- Intel Volume Management Device (VMD): Yes
- Intel Gaussian & Neural Accelerator: 3.0
- Intel Thread Director: Yes
- Intel Deep Learning Boost (Intel DL Boost): Yes
- Intel Speed Shift Technology: Yes
- Intel Turbo Boost Max Technology 3.0: Yes
- Intel Turbo Boost Technology: 2.0
- Intel Hyper-Threading Technology: Yes
- Intel 64: Yes
- Instruction Set: 64-bit
- Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2
- Idle States: Yes
- Enhanced Intel SpeedStep Technology: Yes
- Thermal Monitoring Technologies: Yes
- Security & Reliability
- Intel vPro Eligibility: Intel vPro Enterprise, Intel vPro Essentials, Intel vPro Platform
- Intel Hardware Shield Eligibility: Yes
- Intel Threat Detection Technology (TDT): Yes
- Intel Active Management Technology (AMT): Yes
- Intel Standard Manageability (ISM): Yes
- Intel Remote Platform Erase (RPE): Yes
- Intel One-Click Recovery: Yes
- Intel Control-Flow Enforcement Technology: Yes
- Intel Total Memory Encryption – Multi Key: Yes
- Intel AES New Instructions: Yes
- Secure Key: Yes
- Intel OS Guard: Yes
- Intel Trusted Execution Technology: Yes
- Execute Disable Bit: Yes
- Intel Boot Guard: Yes
- Mode-based Execute Control (MBEC): Yes
- Intel Stable IT Platform Program (SIPP): Yes
- Intel Virtualization Technology with Redirect Protection (VT-rp): Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel VT-x with Extended Page Tables (EPT): Yes
WHAT’S IN THE BOX:
- Intel Core i7-14700 LGA1700 2.1GHz 20-Core Processor x1
